Greenhouse Top

Greenhouse Top Grow Light Series – 250W / 320W

A 250W and 320W top light in a 1200 mm die-cast aluminium body with 220 V input and IP65 sealing. It carries 218 diodes with a chip choice of Samsung, Sanan or Osram, delivers 5000 lm, and is positioned for greenhouse top mounting.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

Die-cast aluminium body, 1200 mm
250W and 320W tiers
218 diodes with Samsung / Sanan / Osram options
IP65 sealing for greenhouse overhead mounting
CE, 220 V input

Model	JL-XQD24-3
Power	250W/320W
Input Voltage	220V
PPE	3.0 µmol/J
Dimensions	1200 mm
IP Rating	IP65

Product Overview

Greenhouse Top Grow Light Series – 250W / 320W

This is a die-cast top light: a single 1200 mm body, 218 diodes, 220 V input and IP65 sealing, built to hang above the crop in a greenhouse rather than to sit close to it. The die-cast housing gives it the rigidity needed for overhead mounting and for cleaning between cycles.

Two power tiers are listed, 250W and 320W, and the diode brand is offered as a choice of Samsung, Sanan or Osram. Output is published at 5000 lm with PPE at 3.0 µmol/J, and greenhouse layouts are normally designed from the per-tier photometric report, which is supplied with the quotation.

Certification is CE and the housing is die-cast aluminium. Input is 220 V, which suits European and Asian supplies; for North American 120 V or 277 V distribution the driver option is specified with the order.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Model	JL-XQD24-3
Power	250W/320W
Input Voltage	220V
PPE	3.0 µmol/J
Dimensions	1200 mm
IP Rating	IP65
Lifespan	50,000 hours
Certifications	CE (EU)
Housing Material	Die-cast aluminum
Luminous Flux	5000 lm
Power Factor	0.95
LED Chip Brand	Samsung / Sanan / Osram optional
LED Chip Count	218 pcs
Brand	boya
Origin	Zhongshan

Available Variants

Model	Power
JL-XQD24-3	250W
JL-XQD24-3	250W
JL-XQD24-3	320W

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

220V

PPE

3.0 µmol/J

Applications

Where It Is Used

Greenhouse top positions above benches
Supplemental lighting in high-humidity houses
Retrofit of single-point overhead fittings

OEM & ODM

Build Your Private-Label Grow Light

Greenhouse Top Grow Light Series – 250W / 320W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

What is a greenhouse top light expected to do that an indoor fixture does not?

Work alongside daylight rather than replace it. A top light in a greenhouse is sized to lift the daily light integral on cloudy days and to extend the photoperiod in winter, so a 250W bar is a supplement to the sun, not the primary source.

Greenhouse lighting

What output does the 250W build quote?

3.0 µmol/J PPE on a 250W and 320W platform. Efficacy is the number that matters in a greenhouse, because every watt is competing with free daylight - a fixture at 3.0 µmol/J needs fewer running hours to add the same photons.

How long is the fixture and how does it mount?

1200 mm, IP65, designed to hang on greenhouse truss above the crop row. That length matches a standard 1.2 m bay spacing, so one fixture per bay is the usual layout rather than a grid of shorter units.

Why IP65 for a greenhouse in particular?

Because greenhouses run at high humidity with condensation dripping from the glazing, and many are washed down between crops. IP65 allows a directed hose and full dust sealing, which an IP54 fixture in the same position does not.

What voltage does it run on?

220V. That is a single-voltage build rather than a wide-range one, so it suits European and Asian greenhouse supplies and needs a step-up arrangement on a 120V North American circuit.

What is the rated life?

50,000 hours, which is the higher figure across our range and appropriate for a fixture that may run 16-18 hours a day through a winter season.

The 320W version is listed too - which should I take?

The choice comes down to bay height and target DLI rather than price. Tell us the crop, the glazing transmission and the latitude of the site and we will recommend one; if you are unsure, the 250W is the more conservative starting point for a 1.2 m bay.
