Quantum Board Grow Light Series – 100W to 480W

A 240W thin-panel board measuring 623 × 260 × 65 mm with 800 diodes and a 240 lm/W rating. It is IP65, which is unusual for a board, and its control set covers smart dimming, remote, timer, WiFi and daisy-chained group control.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

Thin-panel body, 623 × 260 × 65 mm, 4.75 kg
IP65 — spray and condensation resistant
Smart dimming, remote, timer, WiFi and daisy-chain group control
240 lm/W rated
Chip brands offered as an option set, IR diodes optional

Model	BY-ZWLZ-YP-03
Power	100W/120W/240W/480W
Input Voltage	AC100-277V
Spectrum	Customizable Full Spectrum; New LED Array
LED Chips	Options: Samsung / Osram / Sanan / Epistar / Ledestar (IR diodes optional)
Dimming	WIFI (0-10V dimming knob; 480W 0-10V Dimming)

Product Overview

Quantum Board Grow Light Series – 100W to 480W

This is the thin-panel shape rather than a square board: 623 × 260 × 65 mm at 4.75 kg, with the diode array arranged sparsely through the middle and densely around the four edges, according to the supplier’s description of the YP4000 layout. That edge-weighted pattern is intended to even out the falloff at the panel boundary.

Its IP65 rating puts it above the IP54 boards in the same category and makes it usable where spray or condensation is a real risk. Control is the fullest on the board range: smart dimming, remote, timer, WiFi and daisy-chained group control. At 240 lm/W it is the most efficient board.

Power options run 100W, 120W, 240W and 480W, so the panel is offered in several tiers on one body. Chip brands are listed as an option set — Samsung, Osram, Sanan, Epistar, Ledestar — with infrared diodes available, so the fitted chip set is specified with the order. Certification is CE, quoted with certificate reference LCS200301006DE.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Model	BY-ZWLZ-YP-03
Power	100W/120W/240W/480W
Input Voltage	AC100-277V
Spectrum	Customizable Full Spectrum; New LED Array
LED Chips	Options: Samsung / Osram / Sanan / Epistar / Ledestar (IR diodes optional)
Dimming	WIFI (0-10V dimming knob; 480W 0-10V Dimming)
Dimensions	623 × 260 × 65 mm
Net Weight	4.75 kg
IP Rating	IP65
Lifespan	50,000 hours
PPFD	240W PPFD MAP tested in a 2x4ft Grow Tent: Height 12in(30cm) 4x4FT(130cm); Height 18in(45cm) 4FT(120cm); Height 24in(60cm) 4FT(120cm)
Certifications	CE (EU) — supplier-stated, certificate No. LCS200301006DE
Luminous Efficacy	240 lm/W
Power Factor	>0.98
Temperature Rise	30 K
Brand	BOYA
LED Beads	800 pcs
LED Array	YP4000 LED diodes, sparse pattern in the middle and dense pattern around the four sides

Available Variants

Model	Power
YP4000 (120W version)	120W
YP6000 (480W version)	480W

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

AC100-277V

Spectrum

Customizable Full Spectrum; New LED Array

LED Chips

Options: Samsung / Osram / Sanan / Epistar / Ledestar (IR diodes optional)

Dimming

WIFI (0-10V dimming knob; 480W 0-10V Dimming)

PPFD

240W PPFD MAP tested in a 2x4ft Grow Tent: Height 12in(30cm) 4x4FT(130cm); Height 18in(45cm) 4FT(120cm); Height 24in(60cm) 4FT(120cm)

Applications

Where It Is Used

Tents and rooms where spray or condensation occurs
Multi-board rooms controlled as a group
Narrow benches that suit a 623 mm panel

OEM & ODM

Build Your Private-Label Grow Light

Quantum Board Grow Light Series – 100W to 480W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

What is the BY-ZWLZ-YP-03 and which wattages does it cover?

It is a 100W, 240W and 480W quantum board platform, and this page documents the 100W entry build. The 480W version is the one that carries 0-10V dimming as standard; on the smaller builds the control is the WiFi module.

What does the PPFD map tell me that a single PPFD number does not?

It shows how intensity falls off across a 2x4 ft tent at three hanging heights - 12in (30cm), 18in (45cm) and 24in (60cm) - out to the 4 ft edge. A single number hides the edge drop; the map shows it, which is what you actually need when deciding row spacing.

Is the spectrum fixed or customizable?

Customizable full spectrum on a new LED array, so the supplier can build the white/red/far-red ratio to your recipe rather than only offering a stock mix. That also means the spectrum has to be specified at order time - there is no single fixed wavelength table to quote here.

OEM & private label programs Request a quotation

How does WiFi control work if the room has no network?

The WiFi module is for scheduling and remote control; the fixture still runs from its own driver if no network is present. On the 480W build you can use 0-10V dimming instead, which is the safer choice for a site with restricted network access.

Indoor growing lighting

IP65 - can this board be washed down?

IP65 adds jet protection to full dust sealing, so a directed hose is within spec and the board is a reasonable choice for rooms that get cleaned between cycles. It is not submersible; do not soak or immerse it.

What are the physical dimensions and weight?

623 x 260 x 65 mm and 4.75 kg net. It is a long, narrow board rather than a square panel, which suits hanging between rows or over a bench where the light needs to run along the crop rather than spread in a circle.

What certification does it carry?

CE, with certificate reference LCS200301006DE available on request. If the destination is North America and you need a recognised listing there, say so before the order - the CE build on this page will not satisfy a US inspector.
