Foldable LED Bar Grow Light Series – 1300W / 1500W

A 1300W and 1500W wide-board fixture in an 1800 mm length, finished in champagne gold. It is rated 208,000 lm at 160 lm/W with Samsung diodes, knob dimming, IP54 protection and CE, and gives a 3K temperature rise for continuous operation.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

Wide-board format in an 1800 mm length
1300W and 1500W tiers on the same emitter set
208,000 lm at 160 lm/W with Samsung diodes
Champagne gold housing, 16 kg, IP54
CE, certificate reference NTC-SC2409006

Power	1300W/1500W
Input Voltage	110-277V
LED Chips	Samsung
Dimming	Knob dimming
Dimensions	1800mm
Net Weight	16 kg

Product Overview

Foldable LED Bar Grow Light Series – 1300W / 1500W

This is a wide-board format rather than a multi-bar frame: one 1800 mm assembly per fixture, with the diodes spread across a broad panel instead of being concentrated in narrow bars. That shape produces a softer distribution at short range, which suits rooms with low ceilings where bar fixtures would create hot stripes.

The model is offered at 1300W and 1500W. Output is stated at 208,000 lm with 160 lm/W on Samsung diodes, so the two tiers differ in input power rather than in emitter type. Dimming is a knob, housing is IP54 with a 3K temperature rise, and the fixture weighs 16 kg — light for its length, which keeps the hanging load modest.

The finish is champagne gold, a housing colour chosen for showroom and retail-facing installations as much as for the grow room. Certification is CE, quoted with certificate reference NTC-SC2409006. The published dimension line covers length; overall width and height for bracket clearance are confirmed on the outline drawing supplied with the quotation.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Power	1300W/1500W
Input Voltage	110-277V
LED Chips	Samsung
Dimming	Knob dimming
Dimensions	1800mm
Net Weight	16 kg
IP Rating	IP54
Lifespan	50,000 hours
Certifications	CE (EU)
Housing Material	Aluminum
Luminous Flux	208000 lm
Luminous Efficacy	160 lm/W
Power Factor	0.95
Temperature Rise	3K
Certificate No.	NTC-SC2409006 (supplier-stated)
Housing Color	Champagne gold

Available Variants

Model	Power
1300W	1300W
1500W	1500W

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

110-277V

LED Chips

Samsung

Dimming

Knob dimming

Applications

Where It Is Used

Low-ceiling rooms where bar fixtures stripe the canopy
Showroom and retail-facing installations
Long single-fixture runs over continuous beds

OEM & ODM

Build Your Private-Label Grow Light

Foldable LED Bar Grow Light Series – 1300W / 1500W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

Why does this model sit at 1300W rather than a round number?

Because it is a two-point platform - 1300W and 1500W - where 1300W is the lower build on the same 1.8 m bar frame. The odd figure reflects the driver and diode loading of that specific configuration rather than a marketing target.

How long is the fixture?

1.8 m. That is the defining dimension of this model: it is a long bar meant to run the length of a bench or a greenhouse row, so a room is lit by parallel bars down its length rather than by a grid of square panels.

What diodes and spectrum does it use?

Samsung diodes, with dimming by knob. A full wavelength table is not part of the published specification for this build, so we do not quote nanometre peaks - a spectrum drawing comes with the quotation, and the diode mix is confirmed in writing for contract work.

How much does a 1.8 m bar weigh?

16 kg net. For a fixture this long that is a light number, which means the mounting points rather than the ceiling load are usually the constraint - plan at least two hangers and check the frame for flex at mid-span.

Is 1300W realistic for a greenhouse, or is it indoor-only?

It is used in both, but a 1300W bar in a greenhouse is a supplemental light operating alongside daylight, not a sole source. In an indoor room the same fixture is a primary top light, and the knob dimmer lets it be turned down when the crop does not need full output.

Indoor growing lighting

Does it carry CE?

Yes, this build is CE marked. For North American projects the same bar platform is available with an ETL listing - specify the market when you enquire.

Can I order just the 1500W version instead?

Yes, 1300W and 1500W are both current variants on this frame. If you are unsure which to take, the decision usually comes down to hanging height and target PPFD rather than price - tell us the room and we will recommend one.
