Foldable LED Bar Grow Light Series – 480W to 1200W

A 480W folding fixture from a series that runs to 1200W, carrying 3180 diodes on a 1100 × 1000 × 115 mm frame. It is the only folding model rated IP65, and it declares two-channel dimming with remote, timer, WiFi and RJ14 daisy-chain control.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

IP65 rated — the only wash-down-capable folding model
Two-channel dimming with remote, timer, WiFi and RJ14 daisy-chain
Samsung LM301B / LM301H / LM281B / LM561C diode options
240 lm/W, 25K temperature rise, 16.5 kg
ETL certification, certificate reference 5019206

Power	480W/640W/800W/1000W/1200W
Input Voltage	100-277V
LED Chips	Samsung LM301B / LM301H / LM281B / LM561C
Dimming	2-channel dimming, smart remote, timer, WIFI, RJ14 daisy-chain
Dimensions	1100x1000x115mm
Net Weight	16.5 kg

Product Overview

Foldable LED Bar Grow Light Series – 480W to 1200W

Two things set this fixture apart in the folding range. First, it is rated IP65 rather than IP54, which matters in rooms that get washed down or run at high humidity. Second, its control set is the most complete in the range: two-channel dimming, a remote, a timer, WiFi and RJ14 daisy-chaining are all declared, so a room can be grouped and scheduled without a separate controller cabinet.

Diodes are declared as Samsung LM301B, LM301H, LM281B and LM561C — an option set rather than a single fitted part — 3180 in total. Rated efficacy is 240 lm/W with a 25K temperature rise on an aluminium housing measuring 1100 × 1000 × 115 mm, at 16.5 kg. Certification is ETL, quoted with certificate reference 5019206.

The series runs from 480W to 1200W on the same frame, so wattage is chosen at order. The supplier positions the platform on high power, high PPF and high PPE; numeric PPF and PPE are quoted per model, so buyers planning a photon-based layout can request the model-specific photometric table with the quotation.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Power	480W/640W/800W/1000W/1200W
Input Voltage	100-277V
LED Chips	Samsung LM301B / LM301H / LM281B / LM561C
Dimming	2-channel dimming, smart remote, timer, WIFI, RJ14 daisy-chain
Dimensions	1100x1000x115mm
Net Weight	16.5 kg
IP Rating	IP65
Lifespan	50,000 hours
Certifications	ETL (North America)
Housing Material	Aluminum
Luminous Efficacy	240 lm/W
Luminous Flux	288000 lm
Power Factor	>0.98
LED Count	3180
Temperature Rise	25K
Certificate No.	5019206 (supplier-stated)
Product Features	High power, high PPF, high PPE

Available Variants

Model	Power
480W	480W
640W	640W	6 bars, 1/2/3-channel dimming options
800W	800W
1000W	1000W
1200W	1200W

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

100-277V

LED Chips

Samsung LM301B / LM301H / LM281B / LM561C

Dimming

2-channel dimming, smart remote, timer, WIFI, RJ14 daisy-chain

Applications

Where It Is Used

Rooms that are washed down between crops
High-humidity propagation and vegetative areas
Grouped scheduling over WiFi or RJ14 without a controller cabinet

OEM & ODM

Build Your Private-Label Grow Light

Foldable LED Bar Grow Light Series – 480W to 1200W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

Is 480W the only option on this platform?

No - 480W, 640W and 800W are all available on the same frame. This page documents the 480W build, which is the mid-size unit in a three-wattage family aimed at commercial rooms rather than tents.

This build offers remote, timer and WiFi - what is actually included?

Two-channel dimming with a smart remote, an onboard timer, WiFi control and RJ14 daisy-chain ports. The practical effect is that a row of fixtures can be linked and scheduled from one point, with the second channel reserved for a separate spectrum group.

IP65 on a bar fixture - what does that allow?

IP65 adds protection against water jets to the dust sealing that IP54 already covers, which is why this unit is specified for rooms that get washed down between cycles. It is still not a submersible rating - the difference is that a directed hose is now within spec.

Indoor growing lighting

Which diode options are offered?

Samsung LM301B, LM301H, LM281B or LM561C depending on the configuration you order. LM301H is the highest-efficiency of the four; LM281B and LM561C are the cost-optimised choices, so the diode set can be matched to the price point you are selling into.

What are the physical dimensions?

1100 x 1000 x 115 mm unfolded, 16.5 kg net. The 115 mm depth includes the folded bar stack, so check headroom above the canopy when planning hanger positions.

Does the wider 100-277V input matter?

It means one SKU works on 120V North American supplies as well as 230V European ones, which simplifies a distributor stocking a single part number across markets.

Is it ETL listed, and can the listing be documented?

This build is ETL listed for North America. If your customer or inspector needs the listing documentation, ask for it with the quotation and we will supply the certificate reference rather than leaving you to source it after the order.
