Foldable LED Bar Grow Light Series – 240W / 500W

The smallest frame in the folding range: 240W on a 540 × 540 mm footprint, with 0–10V and PWM dimming plus a knob. Rated 108,000 lm at 150 lm/W, it declares 3000K and 6500K white with 460 nm blue, 660 nm red and 730 nm far red, and carries CE.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

540 × 540 mm compact frame, 2 m power cord
0–10V, PWM and knob dimming with RJ45 linking
Declared 3000K / 6500K white plus 460, 660 and 730 nm
108,000 lm at 150 lm/W
CE, certificate NTC-EC2409001

Model	AD4-240-2D412-054
Power	240W/500W
Input Voltage	110-277V
Spectrum	Full spectrum: 3000K + 6500K white + 660nm red + 730nm far-red + 460nm blue
LED Chips	Samsung LM281B
Dimming	0-10V/PWM dimming; knob brightness adjustment

Product Overview

Foldable LED Bar Grow Light Series – 240W / 500W

At 540 × 540 mm this is the compact end of the folding family, sized for benches, trolleys and small rooms where a 1100 mm frame is too wide. It hangs on a 2 m power cord, so a single person can reposition it between crops.

The control section is fuller than the size suggests: 0–10V, PWM and a knob are all declared, and the fixture has an RJ45 connector for linking units. The declared wavelengths are 3000K white, 6500K white, 460 nm blue, 660 nm red and 730 nm far red, which covers both a vegetative weighted mix and a flowering weighted one depending on channel settings.

Output is rated 108,000 lm at 150 lm/W, with a 3K temperature rise and an IP54 aluminium housing. The same platform is also offered at 500W for buyers who need more output from the same footprint, and model-specific photometric data is available on request for either tier. Certification is CE, quoted with certificate reference NTC-EC2409001.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Model	AD4-240-2D412-054
Power	240W/500W
Input Voltage	110-277V
Spectrum	Full spectrum: 3000K + 6500K white + 660nm red + 730nm far-red + 460nm blue
LED Chips	Samsung LM281B
Dimming	0-10V/PWM dimming; knob brightness adjustment
Dimensions	540x540mm
IP Rating	IP54
Lifespan	50,000 hours
Certifications	CE (EU)
Housing Material	Aluminum
Luminous Flux	108000 lm
Luminous Efficacy	150 lm/W
Power Factor	0.95
Temperature Rise	3K
Certificate No.	NTC-EC2409001 (supplier-stated)
Power Cord Length	2 m
Connection	RJ45 cable

Available Variants

Model	Power
240W	240W
500W	500W

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

110-277V

Spectrum

Full spectrum: 3000K + 6500K white + 660nm red + 730nm far-red + 460nm blue

LED Chips

Samsung LM281B

Dimming

0-10V/PWM dimming; knob brightness adjustment

Applications

Where It Is Used

Benches, trolleys and small rooms
Propagation-to-vegetative transitions in tight spaces
Linking several small fixtures on one RJ45 run

OEM & ODM

Build Your Private-Label Grow Light

Foldable LED Bar Grow Light Series – 240W / 500W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

Is this a 240W or a 500W fixture?

Both are available on the same AD4-240-2D412-054 platform - 240W and 500W. This page documents the 240W build; the 500W uses the same 540 x 540 mm folding frame with a larger driver and more diodes.

How large is the fixture, and where does that size fit?

540 x 540 mm unfolded, 5 kg net. That is a compact square module - small enough for a 2x2 ft tent, a single propagation tray or a shelf bay, and light enough to hang from light-gauge racking.

Indoor growing lighting

What spectrum does the 240W build use?

Full spectrum built from 3000K and 6500K white, 660nm red, 730nm far-red and 460nm blue. The 3000K content adds warmth and red that the 6500K alone does not provide, which is why this mix is popular for flowering in small spaces.

Can I adjust brightness without a controller?

Yes. There is a knob brightness adjustment on the fixture plus 0-10V/PWM dimming for external control, so it works standalone or wired into a room system.

What is the input voltage?

110-277V, so the same unit runs on North American and European supplies. That matters for a small module because it is often bought in mixed pallets for several markets.

Is IP54 enough for a humid propagation tent?

IP54 covers splash and condensation, which is what a propagation tent produces. It is not rated for direct spraying, so keep the fixture out of the direct mist path when the dome is off.

Can I brand a small-format fixture like this?

Yes. Branding on a compact module usually goes on the housing end cap and the carton, and spectrum, wattage and plug type can all be set per market. It is a common entry-level private-label item because the tooling is already in place.
