Quantum Board

Quantum Board Grow Light Series – 100W / 200W / 300W (Custom Spectrum)

A 100W board from a 100W, 200W and 300W series that is sold on spectrum customisation rather than a fixed recipe. SAMSUNG diodes give 42,000 lm at 140 lm/W on a 325 × 503 mm panel, with 0–10V knob dimming and CE certification.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

Customisable spectrum for OEM and private-label programmes
SAMSUNG diodes, 42,000 lm at 140 lm/W
0–10V knob with 20% / 50% / 75–100% growth-stage scale
325 × 503 mm panel, 4.16 kg, IP54
CE, certificate reference 5030006

Power	100W/200W/300W
Input Voltage	110-277V
PPE	2.7 µmol/J
Spectrum	quantum board spectrum customizable
LED Chips	SAMSUNG (LM281B/LM301H lamp beads)
Dimming	0-10V knob dimming

Product Overview

Quantum Board Grow Light Series – 100W / 200W / 300W (Custom Spectrum)

This board is the custom-spectrum option in the range: the spectrum is listed as full spectrum and configurable, and the product is tagged for OEM and ODM work. That makes it the natural pick for a brand that wants its own recipe rather than a catalogue spectrum, with the delivered mix specified with the order.

Mechanically it matches the 325 × 503 mm board format at 4.16 kg, with SAMSUNG diodes, 42,000 lm and 140 lm/W. Dimming is a 0–10V knob, with a growth-stage scale of 20% for seeding, 50% for growth and 75–100% for flowering printed on the control card.

The series covers 100W, 200W and 300W. The published 42,000 lm at 140 lm/W and 2.7 µmol/J are headline figures for the series, while each tier carries its own photometric row, so an OEM layout is planned from the per-tier table supplied with the quotation. Certification is CE, quoted with certificate reference 5030006.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Power	100W/200W/300W
Input Voltage	110-277V
PPE	2.7 µmol/J
Spectrum	quantum board spectrum customizable
LED Chips	SAMSUNG (LM281B/LM301H lamp beads)
Dimming	0-10V knob dimming
Dimensions	325 × 503mm
Net Weight	4.16 kg
IP Rating	IP54
Lifespan	30,000 hours
Certifications	CE (EU) — supplier-stated, certificate No. 5030006
Luminous Flux	42000 lm
Luminous Efficacy	140LM/W
Power Factor	0.95
Temperature Rise	3k K
Growth Stage	Seeding 20% -> Growth 50% -> Flowering 75-100% (0-10V knob dimming)

Available Variants

Model	Power	Dimensions
100W	100W	525mm x 520mm
200W	200W	525mm x 520mm
300W	300W	525mm x 520mm

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

110-277V

PPE

2.7 µmol/J

Spectrum

quantum board spectrum customizable

LED Chips

SAMSUNG (LM281B/LM301H lamp beads)

Dimming

0-10V knob dimming

Applications

Where It Is Used

Private-label boards with a specified recipe
OEM programmes needing spectrum flexibility
Rooms running staged dimming through the cycle

OEM & ODM

Build Your Private-Label Grow Light

Quantum Board Grow Light Series – 100W / 200W / 300W (Custom Spectrum) is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

What PPE does this board carry, and at which wattage?

2.7 µmol/J on a platform sold at 100W, 200W and 300W. Efficacy is the figure published for this board rather than PPF, so a PPF is quoted for the specific wattage you order where your tender requires one.

What diode options are available?

Samsung LM281B and LM301H lamp beads. LM301H is the efficiency choice, LM281B the cost-optimised one, and because they sit on the same board footprint the same housing can carry either - which is why the diode mix has to be fixed at order time.

How is the spectrum described?

As a customizable quantum board spectrum rather than a fixed wavelength list. That means the board is built to the ratio you specify; there is no single published nanometre table to quote, and we will not invent one.

Indoor growing lighting

All three wattages share the same board size - does that mean the same dimensions?

Yes, 525 x 520 mm across the 100W, 200W and 300W builds, with the main board 325 x 503 mm and 4.16 kg net. The identical footprint means a rack or hanger built for one wattage takes the others without modification.

What is the dimming arrangement?

A 0-10V knob dimmer on the fixture. It is a continuous analogue control rather than stepped levels, and it accepts an external 0-10V signal if you want to drive it from a room controller.

Is IP54 adequate for a propagation area?

IP54 handles splashing and condensation, which is what propagation domes and misting produce. Keep the board out of the direct mist path - the rating covers incidental water, not continuous spray.

Does it carry a certificate reference I can pass on?

Yes, CE with certificate reference 5030006. If your buyer needs the certificate document itself, request it with the quotation so it arrives before the shipment rather than after.
