Foldable LED Bar Grow Light Series – 400W to 1100W

What separates this fixture from the rest of the folding range is the channel design. It is declared as two-channel with a spectrum of UV-A, infrared, white, red and blue, which means the ultraviolet and infrared bands sit on their own control channel alongside the visible mix. For rooms that would otherwise buy a separate UV bar, that removes a second fixture type from the bill of materials.

Dimming runs on 0–10V and PWM, so the two channels can be scheduled independently from a controller. Diodes are LM281B, 3520 in total on a 1100 × 1100 mm frame, rated 160,000 lm at 160 lm/W. The housing is IP54 aluminium with a 3K temperature rise. Where a room is modelled on photon output rather than lumens, model-specific photometric data is available on request.

The family also lists 1100W, 650W and 400W two-channel builds on the same platform, so a room can be mixed across power tiers while keeping one control architecture. Certification is CE, quoted with certificate reference DL-20210526008C. Because UV is involved, installation planning should include screening and eye protection for staff working under the fixture.
