Intercanopy & Under Canopy

Intercanopy & Under Canopy Grow Light Series – 120W / 150W (Five-Wavelength)

A 1200 mm intercanopy bar rated 120W and 150W, delivering 19,800 lm at 140 lm/W from five declared wavelengths: 3000K warm white, 6500K white, 460 nm blue, 660 nm red and 730 nm infrared. It is IP65, mounts on a bracket or stand, and is supplied in 0.9 m to 2 m lengths.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

Five declared wavelengths including 3000K warm and 460 nm blue
19,800 lm at 140 lm/W — highest of the 1200 mm bars
Available in 0.9 m, 1.2 m, 1.5 m and 2 m lengths
100–277 V input, IP65, 30,000 hour life
CE, certificate reference NTC-SC2409006

Model	150w 120w
Power	120W/150W
Input Voltage	100-277V; 100-277VAC
PPE	2.7 µmol/J
Spectrum	3000k + 6500k + 460nm + 660nm + 730nm (3000K warm + 6500K white + 460nm blue + 660nm red + 730nm IR)
LED Chips	LM281B

Product Overview

Intercanopy & Under Canopy Grow Light Series – 120W / 150W (Five-Wavelength)

This bar carries the fullest spectrum in the intercanopy range: 3000K warm white, 6500K white, 460 nm blue, 660 nm red and 730 nm infrared, all declared as discrete bands. Where the other bars run a cool-white weighted mix, this one keeps a warm channel, which changes the red-to-blue balance at the lower canopy.

Output is 19,800 lm at 140 lm/W on LM281B diodes, the highest of the 1200 mm bars in this range, with a 30,000 hour rated life and a 3K temperature rise. PPE is 2.7 µmol/J. Input range is 100–277 V and the housing is plastic and aluminium, IP65 rated.

Mounting is by bracket or stand, and the same fixture is offered in 0.9 m, 1.2 m, 1.5 m and 2 m lengths so the bar can be matched to row length instead of being cut. Certification is CE, quoted with certificate reference NTC-SC2409006. Net weight is 21.8 kg, which sets the bracket and suspension load for this bar.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Model	150w 120w
Power	120W/150W
Input Voltage	100-277V; 100-277VAC
PPE	2.7 µmol/J
Spectrum	3000k + 6500k + 460nm + 660nm + 730nm (3000K warm + 6500K white + 460nm blue + 660nm red + 730nm IR)
LED Chips	LM281B
Dimming	0-10V dimming voltage; (dimmable)
Net Weight	21.8 kg
IP Rating	IP65
Certifications	CE (EU) — supplier-stated, certificate No. NTC-SC2409006
Luminous Flux	19800 lm
Luminous Efficacy	140 lm/W
Power Factor	0.95
Temperature Rise	3 K
Housing Material	Plastic + aluminium alloy
Beam Angle	120°
Brand	Andi Plant Light
Installation	lifting bracket/stand
Tube Length Options	0.9 m / 1.2 m / 1.5 m / 2 m
Accessories	Brackets (2 pcs), power cord, manual dimmer, RJ14 cable, instruction manual
Dimensions	1200 mm
Lifespan	30,000 hours

Available Variants

Model	Power	PPE	Mounting
120W	120W	2.7 µmol/J	bracket type
150W	150W	2.7 µmol/J

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

100-277V; 100-277VAC

PPE

2.7 µmol/J

Spectrum

3000k + 6500k + 460nm + 660nm + 730nm (3000K warm + 6500K white + 460nm blue + 660nm red + 730nm IR)

LED Chips

LM281B

Dimming

0-10V dimming voltage; (dimmable)

Applications

Where It Is Used

Lower-canopy lighting in mixed-spectrum rooms
Rows needing a warm-white component
Retrofit where bar length must match existing rows

OEM & ODM

Build Your Private-Label Grow Light

Intercanopy & Under Canopy Grow Light Series – 120W / 150W (Five-Wavelength) is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

What is the spectrum on this bar?

3000K warm white, 6500K white, 460nm blue, 660nm red and 730nm far-red - a five-channel mix. The warm white and far-red content suit the flowering response that intercanopy lighting is usually installed for, while 460nm blue keeps leaf quality in the lower canopy.

What PPE does it quote?

2.7 µmol/J. PPE is the figure published for this build; a PPF is quoted per wattage where your tender requires one.

How is dimming implemented?

0-10V dimming voltage with a dimmable driver. That is a hard-wired analogue control rather than a wireless one, which suits rooms that already run 0-10V environmental control and do not want a second control protocol.

What is the beam angle?

120 degrees. Compared with a wider 240-270 degree intercanopy bar, a 120-degree beam concentrates output into a narrower band - it is the choice when the fixture sits close to a specific leaf layer rather than needing to cover a whole inner column.

Does it have a certificate reference?

Yes, CE with certificate NTC-SC2409006. If your customer's compliance file needs the document, request it with the quotation.

IP65 in a wet canopy - what is covered?

Dust sealing plus protection from directed water jets, which covers irrigation splash, runoff and periodic wash-down at canopy height. It is not a submersible rating.

Cannabis cultivation lighting

Can the 150W version be ordered on the same line?

Yes, 120W and 150W are both current builds. The model designation covers both, so the wattage has to be stated explicitly on the order rather than inferred from the model number.
