Propagation & Rack Grow Light Series – 100W / 120W

A 1.2 × 0.6 m rack bar rated 120W and 100W, with 434 Samsung diodes and 10,080 lm at 140 lm/W. It is supplied in bracket, hanging-rope and lifting-stand versions, is IP54 rated, and carries a 20,000 hour rated life.

Get a Quote Request a Sample Contact Sales

Overview

Key Features

1.2 × 0.6 m body matched to a two-tray shelf
Bracket, hanging-rope and lifting-stand versions
434 Samsung diodes, 10,080 lm at 140 lm/W
Full-spectrum recipe with 3000K, 6500K, 660, 730 and 460 nm
IP54, 20,000 hour rated life

Model	SFD1-120-D6-120
Power	120W/100W
Input Voltage	110-277V
PPE	2.6 µmol/J
Spectrum	Full Spectrum White Light (3000K + 6500K + 660nm + 730nm + 460nm)
LED Chips	Samsung LM281B

Product Overview

Propagation & Rack Grow Light Series – 100W / 120W

This bar is dimensioned for a standard propagation tray footprint: 1.2 × 0.6 m, which matches a two-tray shelf without overhang. It comes in three mounting versions — bracket, hanging rope and lifting stand — so the same fixture can be specified for a fixed shelf, a wire rack or a floor trolley.

Diodes are Samsung, 434 in total, rated 10,080 lm at 140 lm/W. The declared spectrum is full-spectrum white with 3000K, 6500K, 660 nm, 730 nm and 460 nm components, which is a general-purpose recipe rather than a blue-heavy propagation mix. Power factor is 0.95 and the housing is plastic and aluminium.

Rated life is 20,000 hours, below the 30,000–50,000 hours usual elsewhere in the range, so replacement planning should use the shorter interval. Unit weight is not part of the published data; freight and rack-load figures are supplied with the quotation.

Specifications

Technical Specification

Parameters are extracted from the product's technical data sheet. Final configuration is confirmed per order.

Model	SFD1-120-D6-120
Power	120W/100W
Input Voltage	110-277V
PPE	2.6 µmol/J
Spectrum	Full Spectrum White Light (3000K + 6500K + 660nm + 730nm + 460nm)
LED Chips	Samsung LM281B
Dimming	dimmable; 0-10V dimming
Dimensions	1.20 × 0.6m
IP Rating	IP54
Lifespan	20,000 hours
Certifications	CE (EU)
Coverage	4x1ft
Brand	ANDI Plant Light
Housing Material	+ (plastic + aluminum alloy)
Origin	Shenzhen, Guangdong
Luminous Flux	10080 lm
Luminous Efficacy	140 lm/W
Power Factor	0.95
LED Chip Count	434
Temperature Rise	3 K
Control Method	dimmable
Color	full-spectrum dimmable plant light tube
Power Options	120W, 100W
Series Connection	Supports connection of up to 18 light bars
Two-Sided Illuminated	Two-sided illuminated light tube
Installation	Support installation between plant rows; replaceable plant-top supplemental; hanging installation

Available Variants

Model	Power	PPE	Mounting
SFD1-120-D6-120	120W	2.6 µmol/J	bracket type
SFD1-120-D6-120	120W	2.6 µmol/J
SFD1-120-D6-120	100W	2.6 µmol/J
SFD1-120-D6-120	100W	2.6 µmol/J
SFD1-120-D6-120	120W	2.6 µmol/J

Photonics

Spectrum & Lighting Performance

Engineered spectrum and output figures for predictable crop response.

Input Voltage

110-277V

PPE

2.6 µmol/J

Spectrum

Full Spectrum White Light (3000K + 6500K + 660nm + 730nm + 460nm)

LED Chips

Samsung LM281B

Dimming

dimmable; 0-10V dimming

Applications

Where It Is Used

Two-tray propagation shelves
Wire racks and floor trolleys
Nursery lines with fixed layer spacing

OEM & ODM

Build Your Private-Label Grow Light

Propagation & Rack Grow Light Series – 100W / 120W is available for OEM and private-label programs. Spectrum, wattage, driver, housing, logo and packaging can all be customized. Minimum order quantities depend on the level of customization — tell us your target market and we will propose a configuration and quotation.

Spectrum & wattage tuning

Custom housing & finish

Private-label packaging

Logo & brand printing

FAQ

Frequently Asked Questions

Practical questions about this grow light — specifications, customization, samples and ordering.

What is the coverage of a 120W rack bar?

4ft x 1ft per bar at 120W, which is one shelf width on a standard propagation rack. The 100W build is also available on the same frame if you need less intensity per tier.

Propagation lighting

Why is this model rated 20,000 hours when others are 30,000 or 50,000?

Because 20,000 hours is the rated life published for this build, and it applies to this model rather than to a family average. If your project requires a longer rated life, the 100W and 120W bars elsewhere in this category are rated 30,000 and 50,000 hours - worth comparing before you standardise on one model.

What spectrum does it run?

Full-spectrum white from 3000K and 6500K with 660nm red, 730nm far-red and 460nm blue. It is the same five-channel approach used across the rack range, so a room can mix this model with the 100W and 50W bars without a visible spectrum mismatch.

How is it dimmed?

0-10V dimming with a dimmable driver. It accepts an external 0-10V signal, so a rack can be run from a single environmental controller rather than a knob per tier.

What are the physical dimensions?

1.20 m x 0.6 m of illuminated area on an IP54 housing. That is a wider footprint than the 55 mm-profile bars, so check the shelf depth as well as the width before ordering.

Which diodes are used?

Samsung LM281B. It is the same diode family as the rest of the rack range, which keeps spares and repair consistent across a mixed installation.

Can it be supplied with a private-label housing?

Yes - housing colour, branding, spectrum and wattage are all configurable. Because propagation racks are often sold as part of a bench system, we can also quote the mounting hardware with the bars so the two arrive matched.
